JZYTJ-600 5-Axis CNC Marble and Granite Cutting Machine
The JZYTJ-600 is a high-precision, 5-axis CNC cutting machine engineered for advanced shaping and milling of marble, granite, and other natural or artificial stones. It is the ideal solution for producing complex 3D sculptures, reliefs, column capitals, vases, and other architectural or decorative elements with exceptional efficiency and accuracy.
Key Features & Advantages
Advanced 5-Axis CNC System
Equipped with a sophisticated 5-axis control system, enabling simultaneous multi-directional cutting for creating intricate three-dimensional shapes and complex contours that are impossible with standard 3-axis machines.
High Precision & Stability
Features a robust heavy-duty steel frame and high-quality linear guides/ball screws, ensuring minimal vibration, superb rigidity, and long-term machining accuracy even under heavy loads.
Powerful Spindle
Powered by a high-frequency water-cooled spindle, providing ample torque and stable performance for smooth cutting, milling, and engraving on hard stone materials.
User-Friendly CNC Software
Compatible with industry-standard design software (e.g., Type3, ArtCAM). The intuitive control system allows for easy import of 3D models, efficient toolpath planning, and seamless operation, reducing programming time.
Automatic Tool Changer (Optional)
Available with an automatic tool changer (ATC) to significantly boost productivity by allowing uninterrupted operation with multiple tools for different machining steps.
Efficient Dust & Slurry Control
Integrated water cooling and dust suppression system keeps the work area clean, extends tool life, and provides a safer working environment.
Applications
Architectural stone components (columns, capitals, moldings)
Stone sculptures and 3D artworks
Memorials and tombstones
Complex kitchen and bathroom countertops
Decorative vases, fountains, and furniture
Customized stone engraving and lettering
For over ten years,We has been at the forefront of the engraving machine industry, dedicated to engineering precision, innovation, and reliability into every solution we provide.
| Project | Parameter | |
|
The machine stroke |
X axis stroke (mm) | 3400 |
| Y axis stroke (mm) | 2000 | |
| Z axis stroke (mm) | 500 | |
| A axis stroke (°) | 0-90 | |
| C axis stroke (°) | ±365 | |
| Cutting thickness (mm) | 0-210 | |
General configuration |
Fast running speed (m/min) | 25 |
| Spindle power (kw) | 18.5-22 | |
| Spindle speed (rpm) | 0-3500 | |
| Saw blade diameter (mm) | 300-700 | |
| Platform size (mm) | 3400*2000 | |
| Flip angles (°) | 0*85 | |
| The total power (kw) | ≈33 | |
| The total weight (kg) | ≈7500 | |
| Equipment dimensions (mm) | 6000*3300*3850 | |
|
Functional Configuration |
Camera function | Yes |
| Knife function | Optional | |
| Thickness function | Optional | |
| Chuck function | Optional | |
| Cutter function | Optional | |
